AIR UNIT (F.R.L. UNIT)
MACP401 series
MACP401-15A-CD, 1/2 Auto Drain
Technical Specifications
| Model | MACP401 |
| Components | MAFR401, MAL401 |
| Bore no. | 8A /10A / 15A |
| Port size | 1/4 / 3/8 / 1/2 |
| Medium | Air |
| Operating pressure range | 0.05~1.5 MPa |
| Proof pressure | 2 MPa |
| Regulated pressure range |
Standard type: 0.1~0.85 MPa |
| Ambient temperature | -5 ~ 60℃ (No freezing) |
| Filter element | Standard: 40μm Option: 5μm |
| Lubricating oil capacity | 200 c.c |
| Min. flow for oil drip | 30 l/min / 65 l/min / 80 l/min |
| Recommended lubricating oil | Turbine oil ISO-VG32 |
| Attachment | Pressure gauge (PG-20), L-type bracket |
